The FLUTREE P100 Pro represents the next generation of intelligent electrical system testers, designed for all 9V–30V vehicle electrical systems. Equipped with a 2.4-inch TFT true color display, this tool delivers accurate real-time diagnostics for professional automotive technicians and enthusiasts alike.

Featuring intelligent voltage and resistance recognition, the P100 Pro automatically identifies electrical parameters for faster and safer troubleshooting. The built-in multimeter mode supports voltage, resistance, and diode testing, while the oscilloscope function visualizes signal waveforms, making it ideal for in-depth circuit analysis.

With its 0–5V adjustable power supply, users can safely activate vehicle components or sensors directly from the device. It also supports frequency (Hz) measurement, online firmware updates, and multiple language options, offering convenience and adaptability for global users.

Compact, durable, and intelligent — the FLUTREE P100 Pro brings advanced automotive diagnostics to your fingertips.

Key Features:

• Supports 9V–30V Vehicle Electrical Systems

• Intelligent Auto-Detection of Voltage and Resistance

• Multimeter Mode: Voltage, Resistance, Diode

• Oscilloscope Function for Signal Testing

• 0–5V Adjustable Power Supply

• Frequency (Hz) Measurement

• Vehicle Component Activation

• Built-in Multi-Language Interface

• Online Network Upgrade Support

• Large 2.4-inch TFT LCD Display

Technical Specifications:

• Display: 2.4-inch TFT (320×240 DPI)

• Working Temperature: 0°C – 60°C (32°F – 140°F)

• Storage Temperature: -40°C – 70°C (-40°F – 185°F)

• Power Supply: 12V / 24V via Vehicle Battery

• Working Voltage Range: 9V – 30V

• Max Measuring Voltage: 100V

• Min Measuring Voltage: 0.1V

• Resistance Range: 1Ω – 200KΩ

• Current Range: 0 – 10A

• Max Continuous Current: 18A

• Available Colors: Black, Red, White, Orange, Yellow, Green, Blue
